CERWIN VEGA AMPLIFIER XED SERIES 4 CH 80W RMS X 4 @ 4OHM / 120W RMS X 4 @ 2OHM

XED6004D - 4 Channel XED Series Amplifier / 600W MAX

Key Features:
• 4-channel full range Class-D car audio amplifier
• High-efficiency Class-D technology for powerful output
• Lightweight aluminum chassis for superior heat dissipation
• Clean, distortion-free sound performance
• Flexible system configuration for speakers or bridged setups
• Ideal for aftermarket car audio upgrades

Specifications:

Power Rating (RMS)

FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 80W X 4
RMS POWER PER CHANNEL 2Ω 120W X 4

Power Supply

• Power Supply: Full WPM
• Power Supply Threshold: 10.0V-16.0V (DC)
• Idle Current: (0.7A)

Distortion

• THD 4 (1KHZ @4Ω): 0.1%
• S/N RATIO (A WEIGHTED @1W): -85dBA
• S/N RATIO (A WEIGHTED @FP): -101.1dBA

Input Sensitivity

• Low Level Input: 250mV-10.0V
• High Level Input: 1.3V~>20.0V

Input Impedance

• Low Level Input: 10KΩ
• High Level Input: 100KΩ

Output Stage

• Output Impedance: 2Ω
• Damping Factor (50Hz@4Ω): >70
• Bandwidth (-3db): 10Hz-3KHz

Crossover (1-12dB/Oct)

• Variable High-Pass: 35Hz-250Hz
• Variable low-Pass: 35Hz-250Hz

Fuse Rating

• 2 x 25A (Inside)

Dimensions

• Length x Width x Height: 7.1”x4.7”x1.8” (180mm x 120mm x 46.5 mm)

FEATURES

• LED Power/Protect Light Indicator
• Selectable X-Over: High Pass/Flat/Low Pass
• 1-year Manufacturer's Warranty
• MFR #: XED6004D
