CERWIN VEGA AMPLIFIER XED SERIES MONO 320W RMS @ 4OHM / 600W RMS @ 2OHM

XED Series 1-Channel Mono Block Amplifier

Key Features:
• 1-channel Monoblock Class-D car audio amplifier
• Designed for powerful subwoofer performance
• High-efficiency amplifier technology for strong output
• Lightweight aluminum chassis for effective heat dissipation
• Clean, distortion-free bass reproduction
• Ideal for aftermarket subwoofer system upgrades

Power Rating (RMS)

FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 320W X 1
RMS POWER PER CHANNEL 2Ω 600W X 1

Power Supply

• Power Supply: Full WPM
• Power Supply Threshold: 10.0V-16.0V (DC)
• Idle Current: (0.7A)

Distortion

• THD 4 (100HZ @4Ω): 0.1%
• S/N RATIO (A WEIGHTED @1W): -85dBA
• S/N RATIO (A WEIGHTED @FP): -101.1dBA

Input Sensitivity

• Low Level Input: 250mV-6.0V
• High Level Input: 1.1V~>20.0V

Input Impedance

• Low Level Input: 20KΩ
• High Level Input: 100KΩ

Output Stage

• Output Impedance: 2Ω
• Damping Factor (50Hz@4Ω): >70
• Bandwidth (-3db): 10Hz-250Hz

Crossover (1-12dB/Oct)

• Variable High-Pass:
• Variable low-Pass: 35Hz-250Hz
• Variable Sub-Sonic: 10Hz-50HZ

Fuse Rating

• 2x30A (Inside)

Dimensions

• Length x Width x Height: 7.1”x4.7”x1.8” (180mm x 120mm x 46.5mm)

FEATURES

• Bass Boost: 0dB-12dB
• LED Power/Protect Light Indicator
• Bass Control Included
• MFR #: XED6001D
